Enclosed Type SMPS 348W 12V 29A LRS-350-12 Meanwell AC-DC Single output Switching power supply LRS-350Series MEAN WELL Power source

Pattern Name:LRS-350-12

348W 12V 29A Single Output Switchable Power Supply 12 Volts 29 Amps

Features AC input range selectable by a switch Withstand 300 VAC surge input for 5 seconds No load power consumption 1U low profile High operating temperature, up to 70°C Protections: Short circuit / Overload / Over voltage / Over temperature Built-in cooling fan, ON-OFF control Compliance to UL 60950-1 Withstand 5G vibration test High efficiency, long life and high reliability LED indicator for power on 100% full load burn-in test 3 year warranty Applications Industrial automation machinery Industrial control system Mechanical and electrical equipment Electronic instruments, equipment or apparatus Related Products LRS-350-3.3 (3.3V 60A, 198W) Jameco P/N: 2219778 LRS-350-4.2 (4.2V 60A, 252W) Jameco P/N: 2219786 LRS-350-5 (5V 60A, 300W) Jameco P/N: 2219794 LRS-350-15 (15V 23.2A, 348W) Jameco P/N: 2219815 LRS-350-24 (24V 14.6A, 350.4W) Jameco P/N: 2219823 LRS-350-36 (36V 9.7A, 349.2W) Jameco P/N: 2219831 LRS-350-48 (48V 7.3A, 350.4W) Jameco P/N: 2219840

Detailed Specifications: Primary Output Voltage (VDC): 12 Output Current (A): 29 Maximum Output Power (W): 350 Family: LRS-350 Input Voltage (VAC): 90 to 132, 180 to 264 Input Frequency: 47 to 63 Maximum Input Current (A): 6.8 Output Connector Type: Screw Terminal Block Number of Outputs: 1 Product Type: AC to DC Power Supply (more.).
